| Model: | ZL-300 |
| Packing material | Laminated film |
| Bag size | L80-400mm W80-280mm |
| Packing speed | 15-70bags/min |
| Machine noise | ≤75db |
| General power | 5.2kw |
| Machine weight | 900kg |
| Air consumption | 6kg/cm² 300L/min |
| Power supply | 220V 50Hz 1PH |
| Outside dimensions | 2125mm*1250mm*1690mm |
1. The whole machine adopts double servo control system, can based on different product and film material to
choose different servo film pulling structure. Can equip with vacuum absorb film system;
2. Horizontal sealing servo control system can realize automatic setting and adjustment of horizontal sealing pressure;
3. Various packing format:pillow bag, side ironing bag, gusset bag, triangle bag, punching bag, continuous bag type;
4. It can be combined with the multi-head weigher, auger scale, volume cup system and other measuring equipment, accurate and measurement;
5. The design of the whole machine conforms to GMP standard and has passed CE certification
Auger scale
● Feature
This type can do dosing and filling work. Due to the special professional design, it is suitable for the fluidity or low-fluidity materials, like milk powder, Albumen powder, rice powder, coffee powder, solid drink, condiment, white sugar, dextrose, food additive, fodder, pharmaceuticals, agriculture pesticide, and so on.
|
Hopper |
Split hopper 25L |
|
Packing Weight |
1 - 200g |
|
Packing Weight |
≤ 100g, ≤±2%; 100 – 200g, ≤±1% |
|
Filling speed |
1- 120 次/分钟,40 – 120 times per min |
|
Power supply |
3P AC208-415V 50/60Hz |
|
Total Power |
1.2 Kw |
|
Total Weight |
140kg |
|
Overall Dimensions |
648×506×1025mm |
Auger lifter
| Speed |
3m3/h |
| Feeding pipe diameter |
Φ114 |
| Machine power |
0.78W |
| Machine weight |
130kg |
| Material box volume |
200L |
| Material box of voulme |
1.5mm |
| Round tube wall thickness |
2.0mm |
| Spiral diameter |
Φ100mm |
| Pitch |
80mm |
| Blade thickness |
2mm |
| Shaft diameter |
Φ32mm |
| Shaft wall thickness |
3mm |
OUTPUT CONVEYOR
● Features
The machine can send the packed finished bag to after-package detecting device or packing platform.
● Specification
| Lifting height | 0.6m-0.8m |
| Lifting capacity | 1 cmb/hour |
| Feeding speed | 30m\minute |
| Dimension | 2110×340×500mm |
| Voltage | 220V/45W |
