MULTIHEAD WEIGHER CANDY PACKING MACHINE – SOONTRUE

Applicable

It is suitable for automatic packaging of granular strip, sheet, block, ball shape, powder and other products. Such as snack, chips, popcorn, puffed food,dried fruits, cookies, biscuits, candies, nuts, rice,beans, grains, sugar, salt, pet food, pasta, sunflower seeds, gummy candies, lollipop, Sesame.

Product Detail

Video Information

Specification

Model:	ZL180PX
Film material	Laminated film
Average speed	20-100 bags/min
Packing film width	120-320mm
Bag size	L 50-170 mm W 50-150mm
Film material	PP.PE.PVC.PS.EVA.PET.PVDC+PVC.OPP+Complex CPP
Air consumption	6kg/m²
General power	4kw
Main motor power	1.81kw
Machine weight	350kg
Power supply	220V 50Hz.1Ph
Outside dimensions	1350mm1000mm2350mm

Main characteristics & Structure features

● 1. The whole machine use 3 servo control system, running stability, high accuracy, fast speed, lower noisy.

● 2. It adopt touch screen operate, more easy, more intelligent.

● 3.Various packing type: pillow bag, punch hole bag, connect bags etc.

● 4. This machine can equip with multi-head weigher , electrical weigher, volume cup etc.

● 5. Entire machine design is more optimized for more convenient operation.

● 6. SS304 machine frame with sand blasted treatment realizes nice appearance.

● 7. Key components are specially designed, fast packing speed.accuracy is more flexible for packing different product

optional accessories

10 HEADS WEIGHER

● Features
1. One of the most economic&stable multi-head weigher in the world the best cost-effective
2. Stagger Dump avoid bigger items pile up
3. Individual feeder control
4. User friendly touch screen equipped with multiple language
5. Compatible with single packaging machine, rotary bagger, cup/bottle machine, tray sealer etc.
6. 99 preset program for multiple tasks.

1_副本

Item	Standard 10 multi heads weigher
Generation	2.5G
Weighing range	15-2000g
Accuracy	±0.5-2g
Max speed	60WPM
Power supply	220V , 50HZ, 1.5KW
Hopper volume	1.6L/2.5L
Monitor	10.4 inches color touch screen
Dimension (mm)	143610861258
Dimension (mm)	143610861388

13_副本

Z-TYPE CONVEYOR

● Features

The conveyer is applicable for vertical lifting of grain material in departments such as corn, food, fodder and chemical industry, etc. For the lifting machine,

the hopper is driven by the chains to lift. It’s used for vertical feeding of grain or small block material. It has advantages of large lifting quantity and highness.

● Specification

Model	ZL-3200 HD
Bucket hopper	1.5 L
Capacity(m³h)	2-5 m³h
Bucket material	PP Food Gradewe have developed dozens of bucket molds ourselves
Bucket style	Slippy bucket
Framework material	Sprocket: Mild steel with chrome coatingAxis: Mild steel with nickel coating
Dimension	Machine height 31001300 mmStandard export case 1.91.3*0.95
Optional parts	Frequency converterSensorPan for leakage product
The material and brand of the internal parts of the machine can be specified , and it can be be selected according to the product and service environment of the machine
